By David Wethe
It’s a fetal-position strategy that could put a fifth of global crude production on the line.
“The industry’s never faced shut-ins like we’re facing right now,” said Clay Williams, chief executive officer for National Oilwell Varco Inc., the biggest U.S. maker of oilfield gear, on an April 28 call with investors. “We are on the precipice of forced well shut-ins totaling 15 to 20 million barrels of oil per day.”
Companies are deciding everything from which wells should be shut first to which should be closed for good, what the costs are, how easy it will be to restart them, and what fields may be too porous to handle a shutdown if you ease operations across hundreds, or even thousands, of wells at once.
Curtailing the output from wells is relatively straightforward. The system of choice today for new wells in the shale patch involves the use of electric submersible pumps, or ESPs, that act as surveillance systems to organize and store data in a centralized location for monitoring and control. They send data from deep within the well to a remote telemetry unit on the surface that transmits it online to production managers.
The goal of these devices is to prevent operating problems from afar before they lead to costly failures. At the same time, these systems allow managers to easily shut down a well as needed.
It’s common practice to shut a well for a month or so while a fracking job is going on in a well nearby, according to Richard Spears, a 40-year veteran of the oil patch and vice president at Spears & Associates, a Tulsa-based industry consultant.
“You’ll be surprised perhaps how simple and non-eventful starting and stopping a shale well is,” Spears said by telephone. “In this world of automated operations, this can often be performed using an iPhone from a production manager’s spare bedroom where he might be working.”
Exxon Chief Executive Officer Darren Woods on Friday said the company will cut back on its newest, most prolific wells first. That essentially allows Exxon to store oil in the ground until prices rise.
“You’re better off deferring that high production rate into a period with better pricing,” Woods said on an investor call. “Depending on how the the market evolves we’ve got the flexibility to bring a lot of those wells back on quickly.”
Generally, non-automated wells can be shut pretty easily as well, something that happens regularly for maintenance. To repair a well requires a service rig and crew to come out at about $500 an hour. In some cases, if wells are shut down for a long time, or permanently, companies will want to pull out expensive equipment to make sure it remains viable. That’s an effort that can cost $75,000 or more.
But there are concerns over the potential fallout from long-term shutdowns. Some operators outside the nation’s shale fields worry that as the flow in a well recedes, the porous nature of rocks in their fields could allow oil to migrate away from the well itself.
For many companies, a key data point in deciding which wells to shut is the operating cost per barrel. Oil has traded in New York for less than $20 a barrel since April 16, closing at $19.78 on Friday. A study by BloombergNEF analysts shows that 45% of the production they surveyed is unprofitable at $30 a barrel while conventional, non-fracked wells and high-cost producers in the Bakken basin in Montana and North Dakota need crude to trade above $45 a barrel.
Over the past month, the U.S., Canada and Brazil accounted for most of a 2.2 million barrel-a-day decline in supply, according to Fatih Birol, the executive director of the International Energy Agency, in an April 22 Bloomberg television interview.
North Dakota has already seen roughly 6,200 wells shut, including 1,700 from shale producer Continental Resources Inc. The total closed-off amounts to more than a third of the state’s active wells.
Overall, Continental eliminated 69,000 barrels a day in April, and the Oklahoma City-based company plans on cutting another 150,000 barrels a day in the next two months, according to industry consultant Rystad Energy. Other companies planning to curb output include ConocoPhillips, Cimarex Energy Co., Parsley Energy Inc., Concho Resources Inc. and Enerplus Corp.
Operations in the Gulf of Mexico, meanwhile, will likely be the last to be shut. The challenge there is the miles of flow lines that carry the oil along the sea bed to processing facilities on shore. At such depths, the liquids in the lines could clog if shut off for too long. While Gulf platforms regularly shut off production for short periods as storms approach, it’s not feasible to keep them shut for long.
“It’s a bad buffet of options,” said Ian Nieboer, a managing director at the industry research firm RS Energy Group, which has been fielding questions over the past few weeks from explorers on the economics of closing wells. “There’s no golden answer.”
The U.S. isn’t the only country working through major shutdowns. As of last week, Western Canadian oil producers shut about 300,000 barrels of daily output, short of the 1 million to 1.5 million barrels that drillers eventually will need to curtail, Bank of Nova Scotia analyst Jason Bouvier said in a note. The earliest are by non-oil sands producers who don’t have direct access to refineries, Bouvier said.
Canada’s oil-sands, the world’s third-largest crude reserve, present particular challenges. Thermal wells — where steam is pumped into the ground to get the viscous oil to flow to the surface — are risky to shut down because dialing back the injections can cause the reservoir to lock up, impairing how much oil can be recovered.
To truly understand the costs of shutting production, timing matters, said Jon Gorrie, a principle analyst at Wood Mackenzie. “It’s one thing to flip a switch on stripper well, and it’s another thing to shut down a field and a battery,” Gorrie said. “What matters the most is the duration of time that you think we’re going to be shut in for.”
Estimated Costs, according to Wood Mackenzie Ltd.
|Pulling the electronic submersible pump from a high-flowing well||$150,000|
|Pull rods from low-flowing well||$75,000|
|Chemical treatment to protect any equipment left in well||$2,000-$5,000|
|Repairing, or “swabbing” a well filled with too much water||$10,000-$20,000|
|Fixing a damaged electronic submersible pump||$150,000|
|Purchase and run new electronic submersible pump||$250,000-$300,000|
|Workover to fix tubing or rods in low-flow well||$50,000|
